ACTIVE IEEE 802.3 AF/AT PoE SWITCH

ACTIVE IEEE 802.3 AF/AT PoE SWITCH

SKU: RG-C210920-ABS-MOQ1-SWTCH-54330
$181.00Price
Excluding Tax |
10-Ports 100M Ethernet Power Switch (PoE Switch), using high-quality high-speed network IC and the most stable PoE chip, PoE Port support 802.3af and 802.3at standard both. 48V PoE Switch can be 10/100M Ethernet. The network provides a seamless connection, and the PoE power port can automatically detect and power the powered devices that comply with the IEEE802.3af or IEEE802.3at standards. The non-PoE device intelligently detects no power and only transmits data. PoE is Power over Ethernet, which refers to the transmission of data signals to some IP-based terminals (such as IP phones, wireless access APs, network cameras, etc.), but also provides DC power for this device. Technology, these devices that receive DC power are called powered devices. With simple and convenient installation and maintenance methods and rich business features, it helps users to build a safe and reliable high-performance network. It is mainly located in the core or convergence layer of user networks such as industrial parks, buildings, factories and mines, government agencies, and residential broadband; it can be widely used in Ethernet access scenarios such as small and medium-sized enterprises, Internet cafes, hotels, and schools.


Operating Modes
N
Standard Normal
all ports communicate freely and adapts to common transmission environment.
V
Port isolation
16 fast ethernet ports isolate from each other and suitable for using environment connected to wireless AP to suppress network storm and promote network performance.
S
Ultral-far mode
Ultral-far mode : designed specially for long-distance application environment  up to 250 meter.
Color: Black
Quantity

  • Technical Specifications

    Model

    W1700P-8G-2S

    Fixed Port

    8*10/100/1000Base-TX PoE port（Data/Power）
    2*1000M SFP

    Network Protocol

    IEEE 802.3
    IEEE 802.3i 10BASE-T
    IEEE 802.3u 100BASE-TX
    IEEE 802.3ab1000BASE-T
    IEEE 802.3x
    IEEE 802.3z 1000BASE-X
    IEEE 802.3af/at

    PoE Standard

    IEEE802.3af/at

    Port Specification

    10/100/1000BaseT（X）Auto

    Transmission Mode

    Store and Forward(full wirespeed)

    Bandwidth

    20Gbps

    Packet Forwarding

    14.44Mpps

    MAC Address

    2K

    Buffer

    2.5M

    Transmission Distance

    10BASE-T ： Cat3,4,5 UTP(≤250 meter)
    100BASE-TX     ： Cat5 or later UTP(150 meter)
    1000BASE-TX     ： Cat6 or later UTP(150 meter)
    1000BASE-SX:62.5μm/50μm MMF(2m~550m)
    1000BASE-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)

    Power Pin

    Default 1/2(+)，3/6(-)； Optional order 4/5(+)，7/8(-)

    Single port power

    Average 15.4W；MAX 30W

    Total power/Input voltage

    MAX 150W （AC100-240V 50/60HZ）

    Watt

    Standby Power Consumption：≤8W；

    LED Indicator

    POWER:Power LED(over-power LED)
    9 10:(SFP LED)
    Port:(Orange=PoE LED+Green=Link LED)

    Power Input

    Built-in power AC：100～240V 50-60Hz 1A

    Operating Temperature/Humidity

    -10～+55°C；5%～90% RH Non coagulation

    Storage Temperature/Humidity

    -40～+75°C；5%～95% RH Non coagulation

    Product

    size/Packing size(L*W*H)

    210mm*140mm*45mm
    270*mm220mm*68mm

    N.W/G.W(kg)

    1.1kg/1.4kg

    Installation

    Desktop (optional wall +machine hanger parts)

    Lightning protection level

    3KV 8/20us；
    IP30

    Certificate

    CE mark, commercial；CE/LVD EN60950；
    FCC Part 15 Class B；RoHS；
